shopMaster GSW-M G30

Flexible with fine-framed ISO-glass > Flexible with fine-framed ISO-glass

shopMaster GSW-M G30

Flexible with fine-framed ISO-glass

Flexibel with fine-framed ISO-glass

The shopMaster GSW-M all-glass sliding partition enables the creation of a multitude of individual partition walls and shop fronts for shop-in-shop concepts. Solutions can be implemented for practically any floor plan, giving completely free reign to the creativity of the planners. Depending on the equipment, the all-glass sliding panel system is available with a linear, curved or segmented design. The units can be arranged in a variety of ways – a floor guide is not needed.

The system’s compact design requires only minimal space for the roller track and parking niche. The use of Swing&Slide panels equipped with a door closer is just one way of providing variable passages.

The running mechanisms are equipped with high-quality, ball-bearing-supported rollers and guarantee permanently reliable operation and smooth movement of the elements during opening and closing.With our GSW-M ISO version the leaves are made of ISO-glass, fine-framed with slim aluminium profiles. That minimises air gaps and reduces energy costs.

Convincing in detail:

  • No continuous floor guide required

  • High-quality, plastic-coated, ball-bearing-supported running mechanisms

  • Modular design with prefabricated function elements

  • Fine-framed leaves dry glazed

Technical Details

shopmaster GSW-M G30
Max. element height
3500 mm*
Max. element width
1250 mm*
Max. element weight
150 kg
ISO-glass laminated (6,5-9-6,5)
22 mm
Roller track version
linear / angled / segmented

silver colour E6 / EV1 anodised

RAL colour as desired (powder coating)

stainless steel look
